8W/m Dotless LED Strip – 4000K – 20m Reel – 24V – 10mm – Indoor IP65 - Uno Lighting
A professional-grade 24V ultra-long-run dotless LED strip, designed for continuous installations of up to 20 metres from a single power feed with minimal voltage drop.
Featuring high-density COB technology with 384 LEDs per metre, this 8W/m strip provides smooth, seamless and dot-free illumination, delivering up to 720lm per metre with CRI 90 for excellent colour quality. The 4000K Cool White output provides a clean, crisp light ideal for kitchens, work areas, retail spaces and commercial applications.
The slim spray-coated Indoor IP65 finish provides additional protection without the bulk of a traditional silicone sleeve, making it particularly suitable for indoor applications such as kitchens and bathrooms.
Product Specifications
| Specification Details | |
|---|---|
| Input Voltage | 24V DC |
| Power | 8W/m |
| Light Output | Up to 720lm/m |
| CRI | 90 |
| LED Density | 384 LEDs/m |
| Strip Width | 10mm |
| Cutpoint | 56mm |
| IP Rating | Indoor IP65 |
| Colour Temperature | 4000K – Cool White |
| Dimmable | Yes – with compatible 24V PWM dimmable driver/controller |
| Maximum Continuous Run | Up to 20m from a single power feed |
| Reel Length | 20m |
| Lighting Effect | Seamless, dot-free linear illumination |
| Application | Residential & commercial indoor installations |
Colour Temperature Guide
| Colour Temperature | Appearance | Recommended Use |
|---|---|---|
| 4000K | Cool White | Kitchens, work areas, retail and commercial lighting applications |
Ultra Long Run Performance
Built-in IC technology helps maintain consistent brightness across the full reel, allowing continuous runs of up to 20 metres from a single-end power input with minimal voltage drop.
This makes the strip particularly suitable for longer installations where reducing the number of separate power feeds is desirable.
Driver Requirements
This LED strip operates at 24V DC and must not be connected directly to 230V mains electricity.
A suitable 24V constant-voltage LED driver is required and is sold separately. The driver should be correctly sized according to the total wattage and length of LED strip being installed.
Installation & IP65 Protection
We recommend installing the LED strip within a suitable aluminium LED profile to provide heat dissipation, protection and a professional finished appearance.
The spray-coated IP65 protection is designed for indoor applications, including kitchens and bathrooms. This product is not recommended for permanent outdoor installation.
Cut sections and electrical connections should be correctly protected where required to maintain the appropriate level of protection. Avoid excessive bending, twisting or pressure on the LED strip during installation.
Important Information
-
This listing is for the LED strip only unless otherwise stated.
-
LED driver, controller, aluminium profile and other accessories are sold separately.
-
All LED strips are tested before dispatch.
-
Do not exceed the recommended 20m maximum continuous run.
-
Please confirm the voltage, wattage, dimensions, colour temperature and IP rating are suitable for your application before ordering.
-
Installation must be carried out by a suitably qualified person.
Electrical Installation Disclaimer
Uno Lighting cannot provide site-specific electrical installation instructions. All mains electrical connections and installation work must be carried out in accordance with applicable electrical regulations by a suitably qualified professional.
