Bespoke Cut IP67 IC NEON COB 3000K Warm White / 4000K Cool White Outdoor Top Bend Low Profile Diffuse/Opal Waterproof Sleeve Strip, 24V Constant Voltage

Cutting Points: Cut points are spaced at 54mm intervals. As the cut points are not visibly marked, we recommend cutting slightly longer than required and carefully peeling back the coating to locate the nearest cut point before making the final cut.

As this is a bespoke service, it can take 3 - 5 working days to prepare the cuts. If there are many cuts or we think it may take longer than usual, we will try to notify customers of any delays and the expected shipping date. Please note that because this is a bespoke service, orders are non-cancellable and non-returnable.

Add to basket in metres only what you need and we will cut it and solder the strip attaching a 15cm long wire/cable to be connected to a LED driver (LED Driver sold separately.

For a customised strip quotation, kindly email your requirements to sales@uno-lighting.com

All Strips cannot be plug direct to the Mains, it will require an 24V Drivers to power.

Our premium IP67 Neon COB LED Strip delivers a seamless, dot-free linear light with exceptional brightness and uniformity. Sold per metre, we custom-cut each order to your required length and professionally solder a 15 cm cable ready for connection to a 24 V LED driver (sold separately).

Key Features

• Sold per metre – custom cut to order
• Neon COB Top-Bend illumination for smooth, even projection
• Low-profile opal waterproof sleeve with an extra-milky diffuser for beautifully soft, glare-free lighting
• Dot-free continuous illumination with invisible LED chips
• 528 LEDs per metre for ultra-high density output
• Flicker-free with all 24V constant-voltage drivers, fully PWM compatible
• IP67 waterproof for outdoor and wet-area applications
• Long-run capability with almost no voltage drop:
• Up to 15m from one end
• Up to 30m powered from both ends
• High CRI 90 for true colour rendering
• Dimmable via remote dimmer, dimmable driver or smart controller / smart speakers (sold separately)
• Professional-grade commercial strip suitable for long-term installations
• Available in: 3000K Warm White, 4000K Cool White
• Includes 3M adhesive backing + optional mounting clips
• 2-Year Warranty, extendable to 3 Years when installed with aluminium profile (recommended for heat dissipation and longevity)

Specifications

• Voltage: 24V DC
• Wattage: 14W per metre
• Brightness: 1540 lm/m
• LED Density: 528 LEDs/m
• IP Rating: IP67 waterproof
• CRI: 90
• Beam Type: Linear, dot-free, seamless output
• Dimensions: W 12mm × H 4mm
• Reel Length: 10m (cut to required length)
• Cut & Solder: 15cm tail cable included
• Mounting Options:
• 3M adhesive tape
• Optional clear clips (15 × 8mm)
• Not Included: 24V LED driver / power supply
• Usage: Must not be connected directly to mains

Installation Guide

All Strips cannot be plug direct to the Mains, it will require an 24V Drivers to power.

This product listing is for LED strip only, power supply/driver are sold separately.

This item is not supplied with a plug, it is supplied with cables ready for a plug to be fitted or hard wired into the mains supply by a qualified professional

• Add the number of metres required to your basket.
• We will cut and solder the strip to your requested length, including a 15 cm tail cable.
• Requires a 24 V LED driver (non-dimmable, dimmable or smart).
• Installation must be carried out by a qualified professional when hard-wiring to mains.
• Maximum recommended run lengths:
• 15 m powered from one end
• 30 m powered from both ends (looped to the same driver)
• Installation options:
• Pre-applied 3M double-sided adhesive backing, or
• Optional clear mounting clips (15 mm × 8 mm) – please request at the time of order
• Suitable for indoor and outdoor use (IP67).
• Avoid bending, twisting, or compressing the strip. Damage caused during installation is not covered by warranty.

Caution: It is recommended to run a maximum of 15 meters continuously in single end power, 30 metres for power both end to avoid any voltage drop and premature failure.

Terms & Conditions:
Bespoke Cutting and Soldering Service for LED Strip
Bespoke Strip Service, please be aware that, due to the customised nature of this service, orders are non-cancellable and non-returnable, and promotional discounts/offers do not apply. Given the bespoke nature, it may take 3 - 5 working days to prepare the cuts. In case of numerous cuts or potential delays, customers will be notified of any extended preparation times and the expected shipping date.

Bespoke Strip Quotations:
All quotations for bespoke strips are formulated based on the information provided by the buyer.
Upon acceptance of the quote, the buyer affirms that the product specifications align with their requirements.
Uno Lighting, as the seller, disclaims any responsibility for products not meeting customer requirements once the order has been placed.

Electrical Information Disclaimer:
Uno Lighting, the seller, cannot provide information about electrical installation or electrical requirements for any lighting or electrical products.
Buyers are strongly advised to consult a qualified professional before contacting the seller regarding project requirements and seeking technical information about installation and maintenance.
By proceeding with a purchase, the buyer acknowledges and agrees to these terms and conditions.

If you require the clear mounting clips please inform us at the point of order.
